The function of the equipment is to complete the automatic assembly of elastic clamps. Clamps and plastic handles are fed by a vibrating plate, automatically assembled, unloaded, etc., and finally the automatic assembly of the clamps is completed.
Product Origin :
ChinaEfficiency :
1200pcs/hourcolor :
RAL7035delivery_port :
FOBdelivery_date :
90daysqty :
1 SetShipping Port :
Fujian xiamenweigh :
0.6Tmodel :
T13Packing :
Wooden Box• WORKFLOW
STEP1: The clamp is automatically loaded by the vibrating plate, and is grabbed by the manipulator into the assembly station.
STEP2: The plastic handle is fed by the vibrating plate and grabbed by the manipulator to the assembly station.
STEP3: After the robot grabbing mechanism is assembled, simultaneously grab the product above the unloading station and release the unloading.
• SPECIFICATION
| Product name | Elastic clamp assembly machine |
| Size |
1800mm(length)*1800mm(width)*1800(height) |
| Weight |
0.6Ton |
| Working area |
2000mm(length)*2600mm(width) |
| Strength |
AC220v,50HZ |
| Pressure |
0.5Mpa-0.7Mpa(72.5-101.5PSI) |
| Efficiency |
1300pcs/hour |
| Service |
One year |
